| Порты |
48x 10/100TX; 2x 10/100/1000/SFP Combo
|
| Производительность |
17.6Gbps
|
| Пропускная способность |
13.09Mpps
|
| Memory |
32MB RAM / 4MB Flash
|
| Буфер пакета |
512KB
|
| VLAN |
IEEE 802.1Q tagged; Port-based; Up to 64 groups
|
| QoS |
IEEE 802.1p tagging; Port-based priority; Four priority; queues per port
|
| IP Multicast Support (IPv4) |
IGMP snooping (v1/v2); Static multicast group; Spanning-Tree, IEEE 802.1d/w; Rapid Spanning-Tree, IEEE 802.1w
|
| IEEE 802.3ad Link Aggregation |
Manual
|
| IEEE 802.1x Port-based and MAC-based
Network Access Control |
Local authentication server (MD5 only); Remote authentication through RADIUS; Dynamic VLAN assignment; RADIUS client for IEEE 802.1x; DHCP client; Statistics charts in Web
|
| Особенности |
IEEE 802.3x flow control or HOL (†) blocking
prevention († when flow control is off); Port mirroring; Destination MAC filtering; Ingress/egress rate limiting; Broadcast storming control
|
| Управление |
Switch discovery management up to 254 switches; Monitor list; Trap view; Device setting; Firmware upgrade by FTP and Web; Configuration back-up/restore by FTP; Factory reset; Password access control and restricted IP
access list; SNMPv1/v2c
|
| Размеры, мм |
444 x 322 x 435
|
